OPERATION
CLINICAL RESOURCES LIBRARY USING USER PROTOCOLS (continued)

View Electrode Placement

Press the Electrode Placement button to
view the electrode placement for the User
Protocol selected.
ELECTRODE PLACEMENT
BUTTON
Press the Next Page button to view text
relating to the electrode placement.
Press the Back button to return to the
Treatment Review screen.

Prepare Patient

Refer to pages 35 through 38 for
Electrotherapy and page 39 for Ultrasound
patient preparation instructions. For sEMG
and sEMG+Stim patient preparation, refer
to the sEMG and sEMG+Stim Module User
Manual.
NEXT PAGE
BUTTON

Edit Modality Parameters

Press the Edit button.
Edit modality parameters as prescribed.
Refer to page 44 for Electrotherapy
modalities and page 49 for Ultrasound.
Refer to the sEMG and sEMG+Stim Module
User Manual for sEMG and sEMG+Stim
modalities.
BACK
BUTTON

Patient Interrupt Switch

Make certain the Patient Interrupt Switch,
for the channel(s) being used, is connected
to the Therapy System. Refer to page 13 for
Symbol Definitions.
EDIT
BUTTON
NOTE:
When reinstalling the Front Access Panel,
make certain the Lanyard does not become
kinked.
82
Intelect® Advanced Therapy System
LANYARD
PATIENT
INTERRUPT
SWITCH
