OPERATION
PATIENT DATA CARD SET UP OF NEW CARD

General Information

The Intelect Advanced Therapy System incorporates a Patient Data Card reading and recording device that allows transfer of patient therapy
data from the system to the card for reviewing patient modality and pain profile information. Information may be transferred to a PC via the
optional Patient Data Management System. The PC software is designed to allow easy access to patient data and printing of reports as well as
adding session notes to the Patient Data Card.
The reading and recording device allows storage and recall of the following patient session data onto the Patient Data Card: therapy session
parameters, Electrode Placement, Pain Map, Numeric Pain Scale or Visual Pain Scale, and Session Notes (stored on card via PC only). Each
Patient Data Card can store multiple sessions and each session can be recalled on the Intelect Advanced Therapy System.

Insert New Patient Data Card

Insert a new Patient Data Card into the
system access port as shown below. The
Therapy System will automatically format
the new Patient Data Card and a verification
message will appear.
Press any button to continue.
INSERT NEW
PATIENT DATA CARD

Setup Treatment

Set up the patient's prescribed treatment.
Refer to the appropriate area of this manual
for modality set up.
Administer treatment as prescribed. When
treatment is complete, the Treatment
Review screen will be visible.
PRESS ANY BUTTON
TO CONTINUE

Set Up of New Patient Data Card

With new Patient Data Card inserted in
the system, press the Save to Patient Card
button.
SAVE TO
PATIENT CARD
BUTTON
63
Intelect® Advanced Therapy System
