INSTALLATION/REMOVAL
INSTALLATION CHANNEL 3/4 ELECTROTHERAPY MODULE (continued)

Nomenclature

5
4
3
7
8
6
1
2
9 11
10
1. Channel 3/4 Electrotherapy Module
2. Extended Front Access Panel
3. Module to System Mounting Holes
4. Module to System Feet Alignment Indents
5. Power Cord Routing Port
6. Module to System Connector
7. Operator Remote Control Connector*
8. Patient Interrupt Switch Connector*
9. Channel 3 Lead Wire Connector*
10. Channel 4 Lead Wire Connector*
11. Microcurrent Probe Connector*
Also Included:
• Four 4 mm X 20 mm mounting screws
• Channel 3 and 4 Lead Wires
• Patient Interrupt Switch (Ch 3/4)
• Carbon Electrodes
• Electrode Sponges
• Sample of Dura-Stick™ II electrodes
• Nylatex Wraps
®
* Refer to page 13 for Symbol Definitions.
