NOMENCLATURE

Below are the definitions for all of the unique terminology used throughout this manual. Study these and become familiar with these
terms for ease of system operation and familiarization with the components and control functionality of the Intelect Adavnced Therapy
System. Some of these terms and definitions refer to a specific button or control on the system. Refer to

GENERAL TERMINOLOGY

Back button
The dedicated button on the Main unit, below the display, that
each time pressed takes the user back one screen at a time.
Previous Page button
The button used in some modalities and functions that will take
the user back one page when reading multiple pages of text.
UP and DOWN Arrows
Controls used in various modality parameter screens to navigate or
change a value up or down within the parameter.
Electrotherapy
Refers to the Electrical muscle or nerve Stimulation modalities of
the system.
System
The primary system with all controls and functions.
Module
Any optional modular modality component designed for
installation onto the System.
ULTRASOUND
1
2
1. Sound Head
That component of the Applicator that makes contact with
the patient during Ultrasound or Combination therapy.
2. Applicator
The assembly that connects to the System and incorporates
the Sound Head.
3. Coupling LED
The component of the Applicator which indicates if
the Sound Head is Coupled or Uncoupled on the the
treatment area.
14
Intelect® Advanced Therapy System
page 13
for Symbol Definitions.
3
