Contactor Ratings

The table below lists the recommended contactor ratings for
integrated axis modules installed without a line interface module.
Catalog Number
Contactor
230V IAM
2094-AC05-MP5-S
100-C23x10 (ac coil)
100-C23Zx10 (dc coil)
2094-AC05-M01-S
100-C37x10 (ac coil)
2094-AC09-M02-S
100-C37Zx10 (dc coil)
100-C72x10 (ac coil)
2094-AC16-M03-S
100-C72Zx10 (dc coil)
100-C85x10 (ac coil)
2094-AC32-M05-S
100-C85Zx10 (dc coil)

Transformer Specifications for Control Power Input

Attribute
Input volt-amperes
Input voltage
Output voltage
Specifications and Dimensions
Catalog Number
460V IAM
2094-BC01-MP5-S
2094-BC01-M01-S
2094-BC02-M02-S
2094-BC04-M03-S
2094-BC07-M05-S
Value (460V system)
750VA
460V ac
120...240V ac
Publication 2094-UM001A-EN-P — September 2006
179
Contactor
100-C23x10 (ac coil)
100-C23Zx10 (dc coil)
100-C37x10 (ac coil)
100-C37Zx10 (dc coil)
100-C60x10 (ac coil)
100-C60Zx10 (dc coil)
100-C72x10 (ac coil)
100-C72Zx10 (dc coil)
