186 Specifications and Dimensions
2094-BC04-M03-S (460V) shown
Power Rail
additional clearance required for
premolded cable connectors.
Publication 2094-UM001A-EN-P — September 2006
Integrated Axis Module Dimensions
2094-AC16-M03-S and -AC32-M05-S (230V)
2094-BC04-M03-S and -BC07-M05-S (460V)
A
B
8.9
(0.35)
2090-XXNFxx-Sxx (flying lead) Feedback Cable with
2090-K6CK-D15Mxx Low-profile Connector Kit
(2.45)
This view illustrates the
Modules are shown mounted to the power rail and the dimensions
reflect that in the depth of the module.
IAM Dimensions
Kinetix 6000 IAM
2094-AC16-M03-S
2094-AC32-M05-S
2094-BC04-M03-S
2094-BC07-M05-S
Dimensions are in millimeters (inches)
C
62
Important: Additional clearance below the connector
is necessary to provide the recommended cable-bend
radius.
2090-UXNFBxx-Sxx (premolded connector) Feedback Cable
A B
mm (in.) mm (in.)
198 (7.8) 176 (7.0)
272 (10.7) 249 (9.8)
F
E
C E F
mm (in.) mm (in.) mm (in.)
125 (4.9)
302 (11.9) 420 (16.5)
196 (7.7)
256 (10.1) 374 (14.7)
196 (7.7)
318 (12.5) 436 (17.2)
