TV User Interface Operation

In addition to Web interface, the Polycom® RSS™ 4000 also provides TV UI
for end users to perform the most commonly used recording and playback
operations through the remote control. The TV UI (User Interface) from
Polycom® RSS™ 4000 system will display on the screen after an endpoint
dials the Polycom® RSS™ 4000 and sets up a connection successfully.

Introduction to Main Menu Page

After the endpoint sets up connection with the Polycom® RSS™ 4000 system,
it enters the TV UI menu page, where common recording and playback
options are provided, as shown below. If the Recording Immediately
function has been enabled in the VRR used by the endpoint for dialing, the
endpoint enters Recording page directly. When the recording is stopped or
cancelled, the endpoint returns back to the main menu page.
Figure 5-1 TV UI Main Menu in Polycom® RSS™ 4000 System
You can control the Polycom® RSS™ 4000 using the FECC and DTMF
functions of the remote control. When your endpoint supports FECC or
DTMF, use the remote control to operate the TV UI menu page. You need to
press the far end key on the endpoint's remote control to access the TV UI.
The table below defines in detail the FECC and DTMF operation keys on the
remote control of Polycom endpoint.
