Chapter 4 - Administrator Configuration
•
•
•
•
•

Running the System in Maximum Security Mode

1
2
3
4
5
6
4-42
Multicast, live streaming, email notification, and reservation VRR fields
are disabled and not configurable.
Telnet and serial port accesses are disabled and not configurable.
All security features are enabled and have strict restrictions on security
policy.
LAN 2 port is activated and used for management traffic, while the LAN
1 port is used for signaling traffic separately.
Antivirus protection is available under the license control.
Be sure you have made necessary data backup before switching the system
work mode. After running the Polycom® RSS™ 4000 system in maximum
security mode, all the configurations made in the normal mode are restored
to factory default settings.
Since the signaling traffic and management traffic go separately through LAN 1 and
LAN 2 port when the Polycom® RSS™ 4000 system runs in maximum security mode,
you may need to connect the two ports to corresponding networks and set the IP
address of your management computer accessible to the LAN 2 port in advance.
The default IP address of LAN 2 port is :
•
IP Address: 192.168.1.253
•
Subnet Mask: 255.255.255.0
•
Gateway: 192.168.1.1
To run the system in maximum security mode:
Connect a USB hard disk to the USB port on the back panel of the
system.
Restart the system.
In the browser address line, enter https://<system LAN 1 IP address>.
In the Out-of-Box Setting wizard that appears, select Maximum
Security Mode and click Next.
Change the default administrator account and enter the password in the
dialog box.
The administrator account is used for logging in to the management
interface. The password you enter should consist of:
― At least 8 characters.
― At least four characters different from the previous password.
― Fewer than two consecutive repeated characters.
― At least two uppercase characters, two lowercase characters, two
numeric characters, and two special characters (` ~ ! @ # $ % ^ & * ( )
- _ = + [ { ] } \ | ; : ' " , < . > / ? ).
Click Next.
