Polycom RSS 4000 User Manual page 51

To configure the IP settings:
1
2
Table 4-21
Parameter
Obtain an IP Address
Automatically (DHCP)
Using the following IP
Address
Enable IPv6
Obtain an IP Address
Automatically (IPv6)
Using the following IP
Address (IPv6)
Enable ICMP V6 DAD
Enable ICMP Echo
LAN Speed
3
Table 4-22
Parameter
Enable Destination
Unreachable Message
Host Name
Domain
Polycom, Inc.
Click System Config>IP Setting in the menu bar at the top of the page.
On the IP Setting page, configure the following parameters:
Signaling Network Parameters Description
Description
Specifies the system to obtain an IPv4 automatically.
Note: Obtaining an IP Address Automatically is not
recommended. For best results, the system should be
configured with a static IP address.
Specifies the system to use a static IPv4 address. You
need to manually enter the IP address and subnet mask.
Specifies whether to enable IPv6 function.
Specifies whether to obtain the IPv6 address automatically
using Stateless Address Auto-configuration (SLAAC).
Specifies whether to configure a static IPv6 address
manually. You need to enter the link local address, site
local address and global address.
Specifies whether to enable the Duplicate Address
Detection (DAD) to ensure the IPv6 address set to the
system is unique in the local network.
Specifies whether to enable the system to respond to an
ICMP echo request (Ping) sent from other devices in the
network. In some high-security environments, you may
need to disable this option to protect the system from Ping
attacks.
Specifies the speed/duplex modes for LAN port. Supports
the 10/100M Full Duplex or Half Duplex mode and the
1000M network. Select Auto to use auto-negotiation.
Note: When setting LAN port speed, contact your network
administrator to ensure that the switch link rate matches
the system port speed.
In the General System Network Settings area, configure the following
settings:
General System Network Parameters Description
Description
Specifies whether to enable the system to forward the
ICMP destination unreachable messages that come from
other network devices when the system is configured to
serve as a router.
Specifies the host name of the system.
Specifies the domain name of the system.
Charpter 4 - Administrator Configuration
4-17
