System Security; Ports; Ping - Polycom RSS 4000 User Manual

Chapter 4 - Administrator Configuration
1
2

System Security

Ports

1
2
3

Ping

1
2
4-34
Click Admin>Disk Warning in the menu bar at the top of the page.
On the Hard Disk Warning page, set a disk space threshold. You can set
a value in the range of 1-50G. The system will send an Email message to
the administrator once the free hard disk space equals this threshold.
The port on Port page used to set firewall to allow H.323 and SIP calls.
To configure the port:
Click System Config>Security Setting>Ports in the menu bar at the top
of the page.
Configure the following parameters on the Ports page:
Table 4-35 Port Parameters Description
Parameter
Fixed Ports for
H.323/BFCP
TCP/UDP Ports
Click Update and confirm to restart the system to apply the setting.
You can use Ping to verify that the Polycom® RSS™ 4000 system can
communicate with another node in the network.
To run Ping on the Polycom® RSS™ 4000 system:
Click System Config > Security Setting > Ping.
Enter an IP address or host name and click Ping.
Description
Specifies whether to define the TCP and UDP ports.

Leave this check box clear if you are defining a Network
Service for local calls that does not require configuring a
firewall to accept calls from external entities. When this
option is not selected, the system uses the default port
range.

If the firewall is incompatible with H.323 or SIP, enable
this setting and specify the TCP and UDP port ranges.
Shows the default TCP/ UDP port range. The user can set
the start port number here, and the end port number will be
calculated automatically.
Polycom, Inc.
