Table 3-1. Slm-5650C Connectors - Comtech EF Data SLM-5650C CyberLynx Installation And Operation Manual

Connector Group
IF
(Sect. 3.2)
Terrestrial Data
(Sect. 3.3)
Utility
(Sect 3.4)
Power/Ground
(Sect. 3.5)
The DB9 connector provided on the rear panel features threaded nuts to
ensure the mechanical integrity of the mated connections.
External Connectors and Pinouts

Table 3-1. SLM-5650C Connectors

Name Connector Type
Type 'SMA' female
Tx
(L-Band)
Type 'SMA' female
Rx
(L-Band)
MANAGEMENT RJ-45 female
TRAFFIC RJ-45 female
REMOTE 9-pin Type 'D' female
+5 VDC POWER Coaxial 5.5mm/2.5mm
IN DC Power Jack
3–2
SLM-5650C / SLM-5650C-ODU Satellite Modem
Function
IF Output
IF Input
10/100Base-T, Remote Control
10/100/1000Base-T
Serial Remote Interface (RS232),
Analog Automatic Gain Control (AGC)
2
Voltage, and Constellation Monitor
Modem Power
Revision 1
MN-SLM-5650C
