Connect Power Supply
Chapter 3. EXTERNAL CONNECTORS
Connect the direct current (DC) power cable to the proper location on the modem by inserting the
jack and threading the sleeve into the housing. A non-threaded connector may also be used.
2.4
Configuration
If there is any problem with installation or initial operation, read Appendix A.
TROUBLESHOOTING for possible solutions.
Chapter 1. INTRODUCTION
All configurations are implemented locally via the unit's loaded firmware.
Step
Task
1
Read Chapter 1. INTRODUCTION before continuing.
2
Connect the power cable.
3
Turn power ON.
4
Do a check for the correct transmitter (Tx) and receiver (Rx) output signal levels and spectrums.
5
Use the modem web page to configure the unit.
Installation
SLM-5650C / SLM-5650C-ODU Satellite Modem
PINOUTS
AND
2–2
Revision 1
MN-SLM-5650C
