Comtech EF Data SLM-5650C CyberLynx Installation And Operation Manual page 124

Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Statistics SSI= 1 byte
Sample
Interval
Software N/A 43 bytes
Revision
RTC Time TIM= 6 bytes
Temperature N/A 3 bytes
AGC Monitor AGN= 3 bytes
Min Voltage
AGC Monitor AGX= 3 bytes
Max Voltage
Modem IP MIS= 1 byte
Interface
Security
Mode
Serial Remote Control
Description of Arguments
Command or Query.
Used to set the sample interval for the Statistics Logging Function.
SSI=x, where x = 0 to 9 in 10 minute steps.
Note: Setting this parameter to 0 disables the statistics logging function.
Example: SSI=3 sets the logging inverval to 30 minutes.
Query only.
Unit returns the value of the internal software revision installed in the
unit, in the form:
Boot:xx.yy.zz Bulk1:xx.yy.zz Bulk2:xx.yy.zz
Example: SWR=Boot:01.01.01 Bulk1:01.01.01 Bulk2:01.01.01
Command or Query.
A time in the form hhmmss, indicating the time from midnight, where:
hh = hours (00 to 23)
mm = minutes (00 to 59)
ss = seconds (00 to 59)
Example: TIM=231259 (23 hours:12 minutes:59 seconds)
Query only.
Unit returns the value of the internal temperature, in the form of xxx
(degrees C).
Example: TMP=+26
Command or Query.
Used to set the AGC Monitor Min Voltage to x.x (0 to 5 Volts), i.e. -60
dBm
Example: AGN=1.0
Command or Query.
Used to set the AGC Monitor Max Voltage to x.x (0 to 5 Volts), i.e. +15
dBm
Example: AGX=5.0
Command or Query.
Used to set the modem IP Interface security level where:
0 = Normal or Low Level Security (SNMP v1/v2c)
1 = High Level Security (SNMP v3)
Example: MIS=0
SLM-5650C / SLM-5650C-ODU Satellite Modem
Response to
Command
SSI=
SSI?
SSI*
SSI#
N/A
TIM=
TIM?
TIM*
TIM#
N/A
AGN=
AGN?
AGN*
AGN#
AGX=
AGX?
AGX*
AGX#
MIS=
MIS?
MIS*
MIS#
7–30
Revision 1
Query
(Instruction
Response to Query
Code and
Qualifier)
SSI? SSI=x
(see Description of Arguments)
SWR? SWR=Boot:xx.yy.zz Bulk1:xx.yy.zz
Bulk2:xx.yy.zz
(see Description
of Arguments)
TIM? TIM=hhmmss
(see Description of Arguments)
TMP? TMP=xxx
(see Description of Arguments)
AGN? AGN=x.x
(see Description of Arguments)
AGX? AGX=x.x
(see Description of Arguments)
MIS? MIS=x
(see Description of Arguments)
MN-SLM-5650C
