6.2.2
Web Interface – Operational Features
Navigation
This manual uses a naming format for all web pages to indicate the depth of navigation needed to
view the referenced page: "Top Level Tab | 2
For example: "Admin | Access" is interpreted to mean first click the top-level 'Admin' navigation
tab; and then click the 'Access' Page tab.
Web Page Tabs
Chapter 7. REMOTE CONTROL
Each page is divided into one or more operational content tabs.
This manual explains the purpose and operation for each web page on a per-page basis. For
detailed information. See Chapter 7. REMOTE CONTROL.
Execution Buttons
Configuration changes generally do not take effect until a selection has been saved to non-
volatile memory. There may be one execution button per page or multiple execution buttons
within a page section. The label for each of these buttons is generally self-explanatory, e.g.,
[Submit], [Clear], [Refresh], etc.
All execution buttons serve the same purpose – to save the configuration changes to non-volatile
memory, or to execute an update of the active page display.
Always make sure to click the execution button before selecting another web
page. Any changes made on that previous page will not be saved if the
execution button for those functions is not clicked.
Feature Selection
Drop-down menus provide access to multiple setting selections, where available, for a specific
function. Move the cursor to the drop-down tab, and then left-click the tab. The drop-down will
open and list the available selections. Move the cursor to the desired choice and then left-click
once again to select that choice.
Modem Configuration
nd
Level Tab."
Figure 6-4. Navigation Tab Examples
6–3
SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
MN-SLM-5650C
