Status | Event Log

Use this read-only page to view a scrollable display of recorded modem events.
Click [Refresh] to update the display with the most recently logged events.
Click [Clear Log] to clear the log. Once the log is cleared, the next time [Refresh] is clicked any
new events are logged and numbered beginning with '1'.
Description
Event Log
Modem Configuration

Figure 6-21. Status | Event Log Page

(Event #) Date / Time:
The first three columns display the event by the order in which it was logged, along
with the date and time the event was recorded.
Type:
The event is identified by its type in this column. Four event types are classified:
Info
•
Unit
•
Tx Traffc
•
Rx Traffic
•
Code:
Click on a hyperlinked fault code to display a page that describes the error code bit
positions.
