Command
Arguments
Parameter
(Instruction
for Command
Type
Code and
or Response
to Query
Qualifier)
Retrieve next
N/A
155 bytes
5 unread
AUPC Log
Entries
AUPC
RCL=
1 byte
Remote
Carrier Loss
Action
Remote
RPB=
1 byte
Modem
Pattern
Substitution
Remote
RPC=
1 byte
Modem
AUPC
Enable
Remote
N/A
6 bytes
Modem
BERT BER
Serial Remote Control
Description of Arguments
Query only.
Unit returns the oldest 5 AUPC Log Entries which have not yet been read
over the remote control.
Reply format: {CR}Sub-body{CR}Sub-body{CR}Sub-body{CR} Sub-
body{CR}Sub-body, where Sub-body=
AA.ABB.BCCC.CEEE.Eddmmyyhhmmss:
AA.A = Minimum Eb/No during sample period.
BB.B = Average Eb/No during sample period.
CCC.C = Max Output Power during sample period.
EEE.E = Average Output Power during sample period.
If there are less than 5 events to be retrieved, the remaining positions
are padded with zeros. If there are no new events, the response is RNA*.
Command or Query.
Tx Output Power level setting when remote carrier is lost, where:
0=Hold current output power level
1=Goto Nominal output power level
2=Goto Maximum output power level
Example: RCL=0
Command or Query.
Remote Modem Tx Pattern Substitution, where:
0=Off
1=On
Note: For compatibility reasons, only the 2047 Tx pattern can be turned
On or Off at the remote modem.
Example: RPB=1 (Turn on remote modem AUPC Control)
Command or Query.
Remote Modem AUPC Control, where:
0=Off
1=On
Example: RPC=1 (Turn on remote modem AUPC Control)
Query only.
Unit returns the value of the remote modem's BERT BER in the form a.b
x 10
. First three bytes are the value. Last two bytes are the exponent.
-c
Returns 0.0E00 if the BERT is not synchronized to a pattern.
Example: RPE=4.0E06
SLM-5650C / SLM-5650C-ODU Satellite Modem
Response to
Command
N/A
RCL=
RCL?
RCL*
RCL#
RPB=
RPB?
RPB*
RPB#
RPC=
RPC?
RPC*
RPC#
N/A
7–34
Revision 1
Query
(Instruction
Response to Query
Code and
Qualifier)
RNA?
RNA=
{CR}AA.ABB.BCCC.CEEE.Eddmmy
yhhmmss{CR}AA.ABB.BCCC.CEEE.
Eddmmyyhhmmss{CR}AA.ABB.BCC
C.CEEE.Eddmmyyhhmmss{CR}AA.
ABB.BCCC.CEEE.Eddmmyyhhmms
s{CR}AA.ABB.BCCC.CEEE.Eddmm
yyhhmmss
(see Description of Arguments)
RCL?
RCL=x
(see Description of Arguments)
RPB?
RPB=x
(see Description of Arguments)
RPC?
RPC=x
(see Description of Arguments)
RPE?
RPE=a.bEcc
(see Description of Arguments)
MN-SLM-5650C
