Command
Arguments
Parameter
(Instruction
for Command
Type
Code and
or Response
to Query
Qualifier)
AUPC Log
ASI=
1 byte
Sample
Interval
Clear All
CAA=
None
AUPC Log
Entries
Initialize
IAP=
None
AUPC Log
Pointer
AUPC Local
LCL=
1 byte
Carrier Loss
Action
AUPC Local
LPC=
1 byte
Enable
Number of
N/A
3 bytes
Unread
AUPC Log
Entries
Serial Remote Control
Description of Arguments
Command or Query.
Used to set the sample interval for the AUPC Logging Function in the
form x, where:
x = 0 to 9 in 10 minute steps.
Note: Setting this parameter to 0 disables the logging function.
Example: ASI=3 (sets the logging inverval to 30 minutes)
Command only.
Forces the software to clear the software AUPC log.
Note: This command takes no arguments.
Example: AAS=
Command only.
Resets internal pointer to allow RNA? queries to start at the beginning of
the stored statistics log.
Command or Query.
Tx Output Power level setting when local carrier is lost, where:
0=Hold current output power level
1=Goto Nominal output power level
2=Goto Maximum output power level
Example: LCL=0
Command or Query.
Local AUPC Control, where:
0=Off
1=On
Note: When Local AUPC Control is enabled, modulator output power is
automatically controlled by the modem. Power output commands via
TPL are not allowed during this mode; although, queries will function as
normal.
Example: LPC=1 (Turn on Local AUPC Control)
Query only.
Unit returns the Number of AUPC Log Entries, which remain Unread, in
the form xxx.
Note: This means unread over the remote control.
Example: NUS=126
SLM-5650C / SLM-5650C-ODU Satellite Modem
Response to
Command
ASI=
ASI?
ASI*
ASI#
CAA=
CAA?
CAA*
CAA#
IAP=
IAP#
LCL=
LCL?
LCL*
LCL#
LPC=
LPC?
LPC*
LPC#
N/A
7–33
Revision 1
Query
(Instruction
Response to Query
Code and
Qualifier)
ASI?
ASI=x
(see Description of Arguments)
N/A
N/A
N/A
N/A
LCL?
LCL=x
(see Description of Arguments)
LPC?
LPC=x
(see Description of Arguments)
NUA?
NUA=xxx
(see Description of Arguments)
