A.3.2.2 Rx Waveform Check
Step
1
Use a spectrum analyzer to check the Rx modulated waveform.
2
The Rx waveform displays the following when receiving a signal from a satellite system:
3
Check all Rx system equipment, including the splitters, if any slope or distortion is present.
Appendix A
a.
A raised noise floor that obscures the low shoulders, similar to Figure A-4.
b.
A flat top without any slope or distortion. Distortion can be caused by overdriven
equipment, impedance mismatches, or faulty equipment.
SLM-5650C / SLM-5650C-ODU Satellite Modem
Task
A–7
Revision 1
MN-SLM-5650C
