A.3.1.2 Slm-5650C-Odu Status Indicators; Table A-2. Slm-5650C Led Conditions; Table A-3. Slm-5650C-Odu Connectors And Indicators; Figure A-2. Slm-5650C-Odu Led Status - Comtech EF Data SLM-5650C CyberLynx Installation And Operation Manual

The following table describes the LED conditions:
Comment
No faults
Rx signal in Tx on
No Receive
Tx off
Tx off
No receive
* Momentary demodulator false lock

A.3.1.2 SLM-5650C-ODU Status Indicators

Appendix A

Table A-2. SLM-5650C LED Conditions

LED Rx LOCK
Green
Off, occasional blink*
Green with demod lock
Off, occasional blink*

Figure A-2. SLM-5650C-ODU LED Status

Table A-3. SLM-5650C-ODU Connectors and Indicators

Item Number
0
1
2
3
4
5
6
7
8
9
SLM-5650C / SLM-5650C-ODU Satellite Modem
LED Tx PWR ON
Green
Green
Off
Off
Description
Power Switch and Indicator
Management
+11 - 33 VDC
PWR / FAULT
Tx PWR ON
A–3
Revision 1
LED PWR/ FAULT
Green blinking
Red Blinking
Green blinking
Red Blinking
Remote
Traffic
Rx
Rx LOCK
Tx
MN-SLM-5650C
