B.1.12 AUPC Mode – Turbo
Modulation Type
BPSK 21/44
BPSK 5/16
QPSK 17/18
QPSK 21/44
QPSK 3/4
QPSK 7/8
OQPSK 17/18
OQPSK 21/44
OQPSK 3/4
OQPSK 7/8
8PSK 17/18
8PSK 3/4
8PSK 7/8
16QAM 3/4
16QAM 7/8
B.1.13 NON-SPREAD LDPC Mode – Ultra Low Latency (ULL)
Modulation Type
BPSK 1/2
QPSK 1/2
QPSK 2/3
QPSK 3/4
Appendix B
Data Rate (kbps)
Min Max
64 13423.295
64 8789.062
64 51840
64 26846.590
64 42187.500
64 49218.750
64 51840
64 26846.590
64 42187.500
64 49218.750
256 51840
256 51840
256 51840
256 51840
256 51840
Data Rate (kbps)
Min Max
32* 2000
32 2000
41.851 2000
46.991 2000
B–14
SLM-5650C / SLM-5650C-ODU Satellite Modem
Symbol Rate (ksps)
Min
143.034
218.453
36.141
71.517
45.511
39.009
36.141
71.517
45.511
39.009
96.376
121.362
104.025
91.022
78.019
Symbol Rate (ksps)
Min Max
64.868 4054.263
32.434 2027.131
32 1529.239
32 1361.979
Revision 1
Max
29999.998
29999.998
29274.352
29999.998
30000
30000
29274.352
29999.998
30000
30000
19516.235
24576
21065.142
18432
15798.857
DR to SR
Multiplier
2092/1032
2092/2064
2092/5448
2092/3072
