Danfoss AK2-SC 255 Reference Manual page 97

SC4 heating
configuration
96
Ambient temp lockout:
No cooling below
Range +/-
Minimum run time
Delay between stages
No of zone sensors
Controlling sensor
Num of ht rclm stages
Setpoint
Range +/-
AK2-SC 255 Reference Manual
until the temperature reaches 70.
(List box: Yes, No) Whether or not there is to be a
lockout based on low ambient temperature.
(0.0 to 100.0) The ambient temperature below which
cooling will be locked out.
(0.0 to 9.9) The range for the lockout. Cooling will be
locked out at lockout minus range, and when locked out
will be allowed on at lockout plus range.
(0 to 20) The number of minutes that a stage must run
before being turned off.
(0 to 20) The number of minutes that must elapse
after a stage is turned on before the next stage can be
turned on.
(0 to 5) The number of zone temperature sensors.
(List box:)
Min Temp: Control will be based on the lowest value
of all of the zone temperature sensors.
Max Temp: Control will be based on the highest
value of all of the zone temperature sensors.
Average: Control will be based on the average of all
the zone temperature sensors.
Zone Temp 4-1 (etc.): (each zone temperature
sensor will be available as a choice in the list) Control
will be based on the single selected sensor.
(0 to 4) The number of heat reclaim stages in the SC4
unit.
(0.0 to 100.0) The desired temperature at the control-
ling sensor when heat reclaim is being used.
(0.0 to 9.9) The range selected creates a dead band.
RS.8D.M1.22
