Writing the custom
strategy
Data definitions
Name
146
Navigate back to the Configure Ca-01 [or whatever number] screen now, which we
will repeat on the left as it looks when it first comes up. After selecting OI as the
type, the screen looks as shown at right. The type cannot be changed from OI unless
Ca-01 is removed as the controlling point for the miscellaneous RO we created.
Notice the Undo and Cancel button fields in the heading of the screen. Undo will
erase your last step if you make a mistake; Cancel will undo all changes, leaving the
point as it was before you started to edit it.
In the Style field, select Generic.
Move to the data definitions area of the screen, and put the cursor over the first
name, which by default says RO1. Toggle to edit mode and open the list box, and the
screen will look as at left below. Select SI °F from the list box and press ENTER.
