Page 1
Instructions AK-PC 651 Identification IP 20 -20 - 60°C (0 - 140°F) RH max. 90% non condensing 080G0312 External display 1,5 m: 080G0075 3,0 m: 080G0076 Termination! MMIGRS2: 080G0294 Termination! Principle RI8RD4ML 2015-04...
Page 2
Factory settings: AI7=Po, AI8=Pc Termination Temperature sensor (Only if a remote display i connected) See above Insert a jumper between the two connections on the left (R120-CANH). AKS 32R AKS 33 AKS 32 Instructions RI8RD4ML © Danfoss 2015-04 AK-PC 651...
Page 3
24 V signal: Connect to DI_ The connection may be a shut-down or interruption function. Select what is to be activated during configuration. DI - Low voltage Digital Inputs, 14 pcs. DI5 - DI18 All 24 V signal. AK-PC 651 Instructions RI8RD4ML © Danfoss 2015-04...
Page 4
The compressor capacity can be controlled from 10 to 67%, depending on the pulse of the unloaders. The relay is then connected to the third unloader. When this relay is on, the capacity will be controlled between 33 and 100%. Instructions RI8RD4ML © Danfoss 2015-04 AK-PC 651...
Page 5
Lembre-se: terminação na terminação do barramento. AI7=Po, AI8=Pc, Sensor de temperatura Terminação Como acima (Somente se um display remoto estiver conectado) Insira um jumper entre as duas conexões à esquerda (R120-CANH) AKS 32R AKS 33 AKS 32 AK-PC 651 Instructions RI8RD4ML © Danfoss 2015-04...
Page 6
A conexão pode ser um desligamento ou uma função de interrupção. Selecione o que deve ser ativado durante a configuração. DI - Entradas digitais de baixa tensão, 14 pçs. DI5 - DI18 Todo o sinal de 24 V. Instructions RI8RD4ML © Danfoss 2015-04 AK-PC 651...
Page 7
O relé é, então, ligado ao terceiro descarregador. Quando este relé for ligado, a capacidade será controlada entre 33 e 100%. The Product contains electrical components AK-PC 651 Instructions RI8RD4ML © Danfoss 2015-04 And may not be disposed together with domestic waste. Equipment must be separate collected with Electrical and Elec-...
