Labfors 5 – Version for Microorganisms
Accessories

5.12 Septum Collars

Page 76 of 205
Inoculation needle, double, Ø 19 mm
Inside-Ø
Outside-Ø hose connection
Fitted with fixed O-ring.
Thread is used for mouting in septum collar in 19 mm port.
Septum collars are either used in combination with the correspond-
ing inoculation needle with septum (piercing membrane) or with a
syringe with injection needle and a septum. Inoculation needles are
always supplied including a septum collar, but septum collars are
separately available, too.
Septum collar, Ø 12 mm
With internal thread.
A septum must be inserted in the 12 mm / Pg13.5 port before
mounting.
A thread is used for mounting.
2.0 mm
4.0 mm
22 January 2019
