Labfors 5 – Version for Microorganisms
Technical Data

13.6.4 Temperature

Page 198 of 205
Impellers
Type / Number
Rushton impellers with 6 blades
Standard: 2 pieces
Option: 3 pieces
Vessel
2 L and 3.6 L / NW 115
3.6 l and 7.5 L / NW 150
13 L / NW 200
Description
Sensor
Heating
Cooling
Range of measure-
ment
Material
316L stainless steel, electro pol-
ished
A B
46 mm 11 mm
54 mm 11 mm
70 mm 13 mm
Value
Type: Pt100 1/3 DIN-B
Double walled vessels:
Water circulation in vessel jacket.
Pump and heating 500 W integrated in
basic unit.
Single walled vessels:
With electrical heater pad
Double walled vessels:
With tap water via water circuit into vessel
jacket
Option: with circulation chiller
Single walled vessels:
With tap water via cold finger in vessel
-5 °C up to +150 °C
C
11 mm
11 mm
19 mm
22 January 2019
