Labfors 5 – Version for Microorganisms
Cleaning and Maintenance

10.3.4 Removing Blanking Plugs

Procedure
Procedure
Procedure

10.3.5 Removing Threaded Adapters

Procedure

10.3.6 Removing the Inoculation Needle, Septum Collar and Septum

Procedure
Page 164 of 205
5. Dispose of the exit gas filter (see also chapter "Removing the
Exit Gas Cooler").
Proceed as follows:
Blanking plugs in 10 mm ports
1. Loosen both slotted screws next to the blanking plug in the
port.
Ensure the screws do not get lost.
2.
Pull the blanking plug out of the port by hand.
Ensure that the O-ring on the blanking plug does not get lost.
Blanking plugs in 12 mm/Pg13.5 ports
1. Loosen the blanking plug with the hexagon socket spanner
and remove it by hand.
Ensure that the O-ring does not get lost.
Blanking plugs in 19 mm ports
1. Loosen the blanking plug with the hexagon socket spanner in
the threaded adapter in the port and remove it by hand.
Ensure that the O-ring does not get lost.
Proceed as follows:
1. Loosen both slotted screws next to the threaded adapter in
the 19 mm port.
Ensure the screws do not get lost.
2. Remove the threaded adapter.
Proceed as follows:
1. Unscrew the inoculation needle from the septum collar by
hand.
Ensure that the O-ring does not get lost.
2. Unscrew the septum collar out of the port or threaded adapter
(in 19 mm port) by hand.
22 January 2019
