Labfors 5 – Version for Microorganisms
Before Fermentation/Cultivation
8.2.9

Inserting the Temperature Sensor (Pt100) into the Pocket

Procedure

8.2.10 Connecting the Antifoam Sensor

Procedure
Page 144 of 205
The temperature sensor is not in direct contact with the medium.
1. Simply insert the sensor into the pocket in the vessel top plate
as far as it will go.
CAUTION
Risk of burns and loss of property due to overheating of the tem-
perature control circuit!
The temperature control circuit will overheat without an inserted
temperature sensor and without liquid in the vessel. This can
lead to burns and loss of property.
To connect the antifoam sensor, the two banana connectors of the
sensor cable must be inserted as follows:
1.
Insert the black banana plug into the earth connection in the
top plate.
22 January 2019
