3.3.3
Top Plate
3.3.4
Ports in the Vessel Top Plate and their Configuration
22 January 2019
Four knurled screws are used to fixate the top plate to the glass
vessel and the vessel holder. Drive hub and motor coupling are lo-
cated in the middle of the vessel top plate.
The vessel top plate has different ports of different sizes to mount
the different components such as sparger, blanking plugs, sensors
etc. The number of ports in the top plate and its configuration de-
pends on the diameter nominal (= inner diameter) of the culture
vessel.
Labfors 5 – Version for Microorganisms
Setup and Function
Page 33 of 205
