8.1.8

Mounting the Blanking Plugs

Procedure
Procedure
22 January 2019
Before Fermentation/Cultivation
For mounting the different blanking plugs, proceed as follows:
Ø 10 mm Ports
1.
Insert the blanking plug with fixed O-ring into the port.
2. Fix it with both slotted screws.
Ø 12 mm ports
1. Insert an O-ring into the port.
2.
Insert the blanking plug and screw it in by hand.
3. Tighten it with the hexagon socket spanner hand tight.
Labfors 5 – Version for Microorganisms
Page 113 of 205
