Infors HT Labfors 5 Operating Manual page 128

Labfors 5 – Version for Microorganisms
Before Fermentation/Cultivation
Procedure
Page 126 of 205
1. Remove the protective cap from the sensor.
Depending on type of clamping adapter:
2. Ensure the clamping adapter or port is equipped with an O-
ring, fit/place one, if necessary.
If 19 mm port: mount a threaded adapter.
3. Insert the sensor into the port and screw it in by hand.
4. Loosen the hollow screw on the clamping adapter.
5. Set the desired mounting depth of the sensor carefully.
6. Tighten the hollow screw on the clamping adapter carefully by
hand.
22 January 2019
