Comparator; Temperature Sensor; Table 16. Humidity Sensor Related Jumper; Table 17. Temperature Sensor Related Jumpers - ST STM32303C-EVAL User Manual

Hardware layout and configuration
Table 16.
Jumper
JP19
2.18

Comparator

VDD_ANA is divided by the resistor bridge of LDR VT9ON1 & 8.2K resistor and connected
to PA0 (COM7_IN+/COM1_IN-/ADC IN1). VDD_ANA is also divided by the RV2
potentiometer and connected to PC1 (COM7_IN+/ADC12).
Figure 4.
VDD_ANA
VDD_ANA
2.19

Temperature sensor

A temperature sensor, STTS751, is connected to the I2C2 bus of STM32F303VCT6 by
setting JP5 and JP6 jumpers, as shown in
Table 17.
Jumper
20/58
Humidity sensor related jumper
A 180 pF 1% capacitor is connected for calibration when
JP19 is set, as shown to the right:
A humidity sensor is connected to measure the humidity
when JP19 is set, as shown to the right: (default setting)
STM32303C-EVAL comparator features
0
PA0
LDR
GND
0
PC1
GND
Temperature sensor related jumpers
An SMB signal connects to the temperature sensor event signal when JP1
is closed.
JP1
Default setting: Not fitted
