RF EEPROM daughter board connector (CN1)

Figure 7.
1. Front view
Table 22.
Pin number
26/58
RF EEPROM daughter board connector (CN1)
RF EEPROM daughter board connector (CN1)
Description
1 SDA(PA10)
2
3 SCL(PF6)
4 RESET(PE14)
Doc ID 023581 Rev 2
Pin number
NC
MS30715V1
Description
5 VDD
6
7 GND
8
UM1567
NC
NC
