CAN D-type 9-pin male connector (CN3)

Figure 9.
1. Front view
Table 24.
Pin number
1, 4, 8, 9
28/58
CAN D-type 9-pin male connector (CN3)
CAN D-type 9-pin male connector (CN3)
Description
2
CANL
Doc ID 023581 Rev 2
Pin number
NC
Description
7
3, 5, 6
UM1567
MS30717V1
CANH
GND
