Connector
3.5

ST-LINK/V2 USB type-B connector (CN5)

The USB connector, CN5, is used to connect the embedded ST-LINK/V2 to the PC for a
board debugging.

Figure 11. USB type-B connector (CN5)

1. Front view
Table 26.
Pin number
3.6

Daughter board extension connectors (CN6 and CN7)

Two 52-pin male headers, CN6 and CN7, can be used to connect with the daughter board or
standard wrapping board to the STM32303C-EVAL evaluation board. All GPIOs are
available on them.The space between these two connectors and the position of the power,
GND and RESET pins are defined as a standard which allows developing common
daughter boards for several evaluation boards. The standard width between CN6 pin1 and
CN7 pin1 is 2700mils (68.58 mm). This standard has been implemented on the majority of
the evaluation boards.
Each pin on CN6 and CN7 can be used by a daughter board after disconnecting it from the
corresponding function block on the STM32303C-EVAL evaluation board. For more details,
refer to Table 27
Table 27.
Pin
1
3
5
7
9
11
30/58
USB type-B connector (CN5)
Description
1 VBUS (power)
2
3
and Table 28.
Daughter board extension connector (CN6)
Description Alternative function
GND -
PC7 MC2_PWM_2H
PC9 I2S_CKIN
PA10 I2C2_SDA
PA11 USB_DM
PC14 OSC32_IN
Doc ID 023581 Rev 2
Pin number
DM
DP
How to disconnect with function block on
-
Disconnect CN4
Remove R247
Keep JP5 open
Remove R266
Remove R196, Close SB12
MS30719V1
Description
4
5, 6
STM32303C-EVAL board
UM1567
GND
Shield
