ETM Trace debugging connector (CN9)

Figure 13. ETM Trace debugging connector (CN9)

1. Top view
Table 30.
Pin number
1
3
5
7
9
11
13
15
17
19
3.9

JTAG/SWD connector (CN10)

Figure 14. JTAG/SWD debugging connector (CN10)

1. Top view
19 17 15 13 11 9 7 5
20 18 16 14 12 10 8 6
ETM trace debugging connector (CN9)
Description
VDD power
GND
GND
KEY
GND
GND
GND
GND
GND
GND
19 17 15 13 11 9 7 5
20 18 16 14 12 10 8 6
Doc ID 023581 Rev 2
3 1
4 2
MS30722V1
Pin number
2
4
6
8
10
12
14 TraceD0/PE3 or SWO/PB3
16 TraceD1/PE4 or nTRST/PB4
18
20
3 1
4 2
MS30722V1
Connector
Description
TMS/PA13
TCK/PA14
TDO/PB3
TDI/PA15
RESET#
TraceCLK/PE2
TraceD2/PE5
TraceD3/PE6
