Hardware layout and configuration
2.10

MicroSD card

The 2 GB (or more) MicroSD card connected to the SPI2 port (Shared with color LCD and
Serial EEPROM) of STM32F303VCT6 is available on the board. The MicroSD card
detection is managed by the standard I/O port, PC6.
2.11

Serial EEPROM

A 1 Mbit (M95M01-R) serial EEPROM connected to the SPI2 port (shared with color LCD
and MicroSD card) of STM32F303VCT6, serial Flash Chip select is managed by I/O pin
PD7.
2.12

RF EEPROM

The RF EEPROM daughter board, ANT7-M24LR-A, is mounted on CN1 to
STM32F303VCT6 via the I2C2 bus.
The I2C address of RF EEPROM is 0b1010000.
The I2C communication depends on JP5 and JP6 jumper setting, as shown in
2.13

EEPROM

To fit the fast mode requirements, a 1 Mbit EEPROM, M24M01-HR, is directly connected to
the I2C2 bus of STM32F303VCT6 by setting JP5 and JP6 jumpers, as shown in
Table 14.
Jumper
JP5,JP6
18/58
EEPROM Related Jumpers
The EEPROM is in Write protection mode when JP8 is closed.
JP8
Default setting: Not fitted
Refer to
Doc ID 023581 Rev 2
Description
Table 10
UM1567
Table 10.
Table 10.
