UM1567
Table 28.
Pin
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
Daughter board extension connector (CN7) (continued)
Description Alternative function
PF0 OSC_IN
PE10 MC1_PWM_2L/ LED3
PE9 MC1_PWM_1H/ LED2
PE7 JOY_UP
PB2 OPAMP3_IN- / 1V8_POR
PB0 OPAMP3_IN+/ Hum_In
PC4 USART1_TX
PA6 OPAMP2_OUT
GND -
PF4 MC1_HeatsinkTemp
PA2 OPAMP1_OUT
PA0 MC1_BusVoltage/ LDR_OUT
PC3 MC1_Bin+_ADC12
PC1 MC2_BusVoltage/ COM_IN+
PC0 MC1_Cin+_ADC12
PD15 MC2_ICL_SHUTOUT/TS2
PD13 MC2_EnB/TS1
PD12 MC2_Bin+_ADC34/TS_CT
PD10 MC2_Cin+_ADC34
GND -
PD8 MC1_MC2_PFC_Ind
PB14 SPI2_MISO
PB10 OPAMP4_IN-
PE14 ACP_RESET/SPI2_DIR
PE13 MC1_PWM_3H / LED_DRV
PE11 MC1_PWM_2H / LED4
VDD -
PF1 OSC_OUT
PE8 MC1_PWM_1L / LED1
GND -
PB1 OPAMP3_OUT
PC5 OPAMP2_IN-
PA7 OPAMP2_IN1+
PA5 MC_DAC_OUT2
Doc ID 023581 Rev 2
How to disconnect with function block
on STM32303C-EVAL board
Remove X2, C51, Close SB14
Remove R27, R28
Remove R25, R26
Remove R309
Remove R21, R245
Remove R19, R20
Remove R177
Remove C33, R117, R118
-
Remove R82, C8
Remove C37, R115
Remove R9, R10
Remove R77
Remove R13, R14
Remove R85
Remove R43, R102, Close SB7
Remove R41, R104, Close SB6
Remove R39, C52, Close SB8
Remove R100
-
Remove R119, R123, C22, C23
Remove R299
Remove C21, R130, R131
Remove R136, R140
Remove R31, R32
Remove R29, R30
-
Remove R205, Close SB15
Remove R23, R24
-
Remove C29, R135
Remove C33, R117, R118
Remove R75
Set PGM2, PG3SA in default position
Connector
