2.3

Clock source

Two clock sources are available on the STM32303C-EVAL evaluation board for
STM32F303VCT6 and RTC embedded:
X1, 32 kHz crystal for embedded RTC
X2, 8 MHz crystal with socket for the STM32F303VCT6 microcontroller; it can be
removed from the socket when an internal RC clock is used.
Table 6.
Solder bridge
SB12
SB13
measurement can be done by the current meter which is mounted on JP12 when it
measurement.
DD
Low voltage limitation
Component
USB
CAN
32 kHz crystal X1 related solder bridges
PC14 is connected to the 32 KHz crystal when SB12 is open (default setting).
PC14 is connected to the extension connector CN6 when SB12 is closed. In such
a case, R196 must be removed to avoid disturbance due to the 32 KHz quartz.
PC15 is connected to the 32 KHz crystal when SB13 is open (default setting).
PC15 is connected to the extension connector CN6 when SB13 is closed. In such
a case, R197 must be removed to avoid disturbance due to the 32 KHz quartz.
