UM1567
3.13
Power connector (CN14)
The STM32303C-EVAL evaluation board can be powered from a 5 V DC power supply via
the external power supply jack (CN14) shown in
positive.
Figure 16. Power supply connector (CN14)
1. Front view
3.14
TFT LCD connector (CN15)
A TFT color LCD board is mounted on the CN15 connector. For more details, refer to
Section
2.20.
Figure
DC +5V
Doc ID 023581 Rev 2
16. The central pin of CN14 must be
GND
MS30721V1
Connector
37/58
