UM1567
Table 27.
Pin
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
2
4
6
8
10
12
14
16
18
Daughter board extension connector (CN6) (continued)
Description Alternative function
PA13 TMS/ SWDAT
PC15 OSC32_OUT
PA15 JTDI
GND -
PD0 CAN_RX
PD2 MC1_MC2_PFC_SD
PD4 MC1_EnB
PD6 JOY_RIGHT
PD7 MC1_EnIndex/ E2P_CS
PB4 TRST
PB6 MC2_EnA
MC2_EnIndex/
PB8
USB_disconnect
PE0 LCD_CS
GND -
MC1_MC2_PFCpwm/
PE3
TRACE_D0
MC1_DissipativeBrake /
PE5
TRACE_D2
PF9 SPI2_SCK
PF10 MC2_DissipativeBrake
D5V -
OPAMP4_IN1+/
PB11
SHIELD_CT
MC2_PWM_1H/
PC6
SDcard_detect
MC2_PWM_3H/
PC8
Hum_Out
PA8 I2C2_SMB/ MCO
PA9 I2S_MCK/ IR_IN
GND -
PA12 USB_DP
PF6 I2C2_SCL
PA14 TCK /SWCLK
MC2_PWM_1L/
PC10
RS485_DIR/ I2S_SCK
Doc ID 023581 Rev 2
How to disconnect with function block on
STM32303C-EVAL board
Disconnect CN9, CN10
Remove R197, Close SB13
Disconnect CN9, CN10
-
Remove R124
Remove R153, R165
Remove C12, Disconnect CN2
Remove R12
Remove R57, R58
Disconnect CN9, CN10
Remove C35, Keep JP7 open, Disconnect
CN4
Remove R17, R18
Remove R250
-
Remove R3, R4
Remove R7, R8
Remove R303
Disconnect CN4
-
Remove R35, R137, Close SB11
Remove R47, R48
Remove R49, R50
Remove R237, Keep JP1 open
Keep JP18 open
-
Remove R260
Keep JP6 open
Disconnect CN9, CN10
Remove R51, R52, R129
Connector
31/58
