Connector
3.15

MicroSD connector (CN16)

Figure 17. MicroSD connector (CN16)

1. Top view
Table 33.
Pin number
1
2
3
4
5
38/58
MicroSD connector (CN16)
Description
NC
MicroSDcard_CS (PE15)
MicroSDcard_DIN (PB15)
+3V3
MicroSDcard_CLK (PF9)
Doc ID 023581 Rev 2
Pin number
6
7 MicroSDcard_DOUT (PB14)
8
9
10 MicroSDcard_detect (PC6)
UM1567
MS30723V1
Description
Vss/GND
NC
GND
