1.6 Connecting the Cables

Connect cables to the Oracle Exalytics In-Memory Machine as follows:
Connect an Ethernet cable to the Gigabit Ethernet (
1.
operating system support. See the part 8 in
(Optional) If you want to interact with the system console directly, connect any
2.
external devices, such as a mouse and keyboard, to the server's USB connectors,
or a monitor to the DB-15 video connector. See parts 9 and 13 in
If you plan to configure network IP address for Oracle Integrated Lights Out
3.
Manager (ILOM), connect an Ethernet cable to the Ethernet port labeled
See the part 12 in
If you plan to access the ILOM command-line interface (CLI) using the serial
4.
management port, connect a serial null modem cable to the RJ-45 serial port
labeled

1.7 Connecting the Power Cords

Connect the power cords to the Oracle Exalytics In-Memory Machine as follows:
Connect two grounded server power cords to grounded electrical outlets.
1.
Connect the two server power cords to the AC connectors on the back panel of the
2.
server.
When power is connected, the server boots into standby power mode. In standby
power mode, the SP OK/Fault LED flashes, but the main Power/OK LED remains off.
After a few minutes, the main Power/OK LED slowly flashes the standby pattern,
indicating the service processor (SP) is working. Note that the server is not initialized
or powered on yet.
Figure 1-5

Figure Legend

1 - Power/OK LED
2 - Power button
3 - SP OK/Fault LED
Figure 1-2.
. See the part 12 in
SER MGT

Front Panel Controls

) connectors as needed for
NET0
Figure 1-2.
Figure 1-2.
Chapter 1
Connecting the Cables
Figure 1-2.
.
SER MGT
