Storage Configuration

This chapter describes the storage configuration for the Oracle Exalytics In-Memory
Machine.
It contains the following topics:
•

Overview of Disk Partitions

• Connecting Exalytics to a Storage Area Network
• For Additional Help
5.1 Overview of Disk Partitions
Table 5-1
Machine.
Table 5-1
Partition
boot
base operating
system, logs,
and temp
space
Software, data
files, and so on
lists the disk partitions configured on the Oracle Exalytics In-Memory
Disk Partitions
Capacity Hardware RAID Mount Point
99 MB RAID1
X6-4: 1.2 TB RAID1
X5-4: 1.2 TB
X4-4: 1.2 TB
X3-4: 900 GB
X2-4: 600 GB
X6-4: 3.6 TB RAID5
X5-4: 3.6 TB
X4-4: 3.6 TB
X3-4: 2.7 TB
X2-4: 1.8 TB
Description
Boot partition
/boot
Partition for the base
/
operating system, logs,
and temp space
The /u01 disk Data partition
partition is
created and
available on
this sdb disk.
5-1
