Figure 3-7
Brackets into the Slide-Rails
Simultaneously push and hold the green slide-rail release buttons
4.
each mounting bracket while you push the Oracle Exalytics In-Memory Machine
into the rack
the mounting brackets) engage the slide-rail assemblies. You will hear an audible
click.
Figure 3-8

3.8 Installing the Cable Management Arm

The cable management arm (CMA) is an optional assembly that you can use to route
the server cables in the rack.
To install the optional CMA, complete the following steps:
Unpack the CMA parts.
1.
Take the CMA to the back of the equipment rack and ensure that you have
2.
adequate room to work around the back of the Oracle Exalytics In-Memory
Machine.
Inserting the Oracle Exalytics In-Memory Machine with Mounting
(Figure 3-8). Continue pushing until the slide-rail locks (on the front of

Sliding the Oracle Exalytics In-Memory Machine Into the Rack

Caution:
Verify that the Oracle Exalytics In-Memory Machine is securely mounted
in the rack and that the slide-rail locks are engaged with the mounting
brackets before continuing.
Chapter 3
Installing the Cable Management Arm
(Figure 3-1) on
3-8
