ib_cm 35714 2 rdma_cm,ib_ipoib
ipv6 290974 5 bonding,cnic,ib_sdp,ib_addr,ib_ipoib
ib_sa 39126 6 rdma_ucm,rdma_cm,ib_ipoib,ib_cm,mlx4_vnic,mlx4_ib
ib_core 66876 12
rdma_ucm,ib_sdp,rdma_cm,iw_cm,ib_ipoib,ib_cm,ib_uverbs,ib_umad,mlx4_vnic,mlx4_ib,ib_s
a,ib_mad
[root@bda10 ~]# lsmod | grep rds
rds 94503 0
[root@bda10 ~]#

8.3 Physical Connectivity

On both GW switches of Oracle Big Data Appliance, four ports are available for
external connections-5A, 5B, 6A, 6B. Oracle recommends that you use ports 5A on
both leaf switches. If these ports are not available, use any other available port on the
leaf switches.
Note:
Never connect a host (HCA) system to the spine switch inside a rack.
If the Oracle Big Data Appliance rack is connected to other Oracle Engineered
Systems, port 5-6[A|B] may not be available. In such a case, it is recommended to use
any other available port on the InfiniBand leaf switch of the Oracle Big Data Appliance
rack. If no free ports are available, contact Oracle Support.
Figure 8-1 shows how to connect an Exalytics to a standalone BDA rack.
