You can use these cables to connect the Oracle Exalytics In-Memory Machine to your
data center's network.

4.2 Overview of Network Ports

Figure 4-1
Machine X6-4, X5-4, and X4-4.
Figure 4-1
Machine X6-4, X5-4, and X4-4
Table 4-1
Table 4-1
X4-4
Call out
1
2
3
4
5
6
7
8
9
10
11
12
Figure 4-2
Memory Machine X3-4, and Oracle Exalytics In-Memory Machine X2-4, respectively.
shows the network ports available on the Oracle Exalytics In-Memory
Network Ports on the Back of the Oracle Exalytics In-Memory
lists out the ports called out in
Back Panel of Oracle Exalytics In-Memory Machine X6-4, X5-4, and
Description
Power supply unit (PSU) 0 indicator panel
PSU 0 AC inlet
PSU 1 indicator panel
PSU 1 AC inlet
System status indicator panel
PCIe card slots 1–6
Network (NET) 10 GbE ports: NET0–NET3
USB 2.0 ports (2)
PCIe card slots 7–11
Service processor (SP) network management (NET MGT) port
Serial management (SER MGT)/RJ-45 serial port
DB-15 video port
and Figure 4-3 show the network ports available on the Oracle Exalytics In-
Overview of Network Ports
Figure 4-1.
