Figure Legend; Inserting Cma Slide-Rail Connector Into The Back Of The Left Slide-Rail - Oracle Exalytics In-Memory Machine Owner's Manual

Table 3-4

Figure Legend

Number
1
2
Insert the left CMA slide-rail connector into the left slide-rail assembly until the
6.
connector locks into place with an audible click, as shown in
Figure 3-11 Inserting CMA Slide-Rail Connector Into the Back of the Left
Slide-Rail
Table 3-5 Figure Legend
Number
1
2
Install and route cables to your Oracle Exalytics In-Memory Machine, as required.
7.
If required, attach the cable hook and loop straps to the CMA, and press them into
8.
place to secure the cables, as shown in
Note:
Cable hooks and loop straps are preinstalled on the CMA. Perform the
procedure in this step if you need to reinstall cable hooks and straps on
the CMA.
Description
CMA slide-rail connector
Right slide-rail
Description
CMA slide-rail connector
Left slide-rail
Figure 3-12.
Chapter 3
Installing the Cable Management Arm
Figure 3-11.
3-10
