protocol mode from a two-port 16 Gb FC HBA to a two-port 10 GbE Fibre Channel
over Ethernet (FCoE) Converged Network Adapter. The universal HBA has four
possible configurations:
•
10 GbE FCoE Copper — This configuration provides twin-ax copper cable
connectivity and 10 GbE FCoE HBA functionality. No optical transceiver modules
are installed in, nor provided with, this configuration of the universal HBA.
•
16 Gb FC SW (shortwave) Optical — This configuration requires installing 16 Gb
FC shortwave optical transceiver modules in the SFP+ connector of the universal
HBA, enabling 16 Gb Fibre Channel HBA functionality.
•
10 GbE FCoE SR (short-range) Optical — This configuration requires installing
10 GbE short-range optical transceiver modules in the SFP+ connectors of the
universal HBA, enabling 10 GbE FCoE Converged Network Adapter functionality.
•
16 Gb FC LW (longwave) Optical—This configuration requires installing 16Gb
FC long-range optical transceiver modules in the SFP+ connectors of the universal
HBA, enabling 16 Gb FC HBA functionality.
Table 4-4
Name
2 Sun Storage 10 Gb FCoE short reach optics,
Qlogic (for factory installation)
2 Sun Storage 10 Gb FCoE short reach optics,
Qlogic
2 Sun Storage 16 Gb FC short wave optics,
Qlogic (for factory installation)
2 Sun Storage 16 Gb FC short wave optics,
Qlogic
2 Sun Storage 16 Gb FC short wave optics,
Emulex (for factory installation)
2 Sun Storage 16 Gb FC short wave optics,
Emulex
4.5 Determining Default Eth0 IP Address
When an Oracle Exalytics In-Memory Machine is delivered, the default IP address that
is configured for the eth0 (physical NET0 port) interface of the machine might vary. It
can be any IP address in the class C subnet
Note:
In case of X2-4, X3-4, and X4-4 4 servers, by default, the NET0 port is
assigned as eth0, and in case of X5-4 and X6-4 Exalytics servers, by default,
the NET0 port is assigned as eth4.
This procedure is used to determine the eth0 IP address if the serial console is set up
on the system.
Transceivers
Determining Default Eth0 IP Address
Part Number
7101677
7101678
7101675
7101676
7101685
7101686
.
192.168.1.0
Chapter 4
4-5
