Table 2-1 (Cont.) Oracle Exalytics In-Memory Machine Hardware
Component
Fiberchannel Card
Hard Disk Drives (HDD)
Cooling Fans
Flash cards
Accessories
Rack Mount Slide Rail Kit
Cable Management Arm (CMA)
Ports and I/O Slots on the Server
USB 2.0 Ports
VGA Ports
PCI Express I/O Slots
Description
For X6-4, X5-4, and X4-4: Two Sun Storage 16 Gb Fiber
Channel PCIe Universal HBA, QLogic
For X3-4 and earlier: One 8Gb Dual-Port Fiber Channel
PCI-Express card
For X6-4 and X5-4: Six 2.5 inch 1.2 TB 10K RPM SAS3
front-accessible, hot-swappable, drive bays (total HDD
memory: 7.2 TB per server)
For X4-4: Six 2.5 inch 1.2 TB 10K RPM SAS2 hard disk
drives (total HDD memory: 7.2 TB per server)
For X3-4: Six 2.5 inch 900 GB 10K RPM SAS2 hard disk
drives (total HDD memory: 5.4 TB per server)
For X2-4: Six 2.5 inch 600 GB 10K RPM SAS2 hard disk
drives (total HDD memory: 3.6 TB per server)
Six hot-swappable, redundant fans at chassis front (top-
loading); redundant fans in each power supply
For X6-4: Three 3.2TB V-NAND Flash F320 NVMe AIC (9.6
TB total) or Three 6.4TB V-NAND Flash F640 NVMe AIC
(19.2 TB total), Aura 6
For X5-4: Three 1.6 TB NVMe PCIe Flash Cards (4.8 TB
total)
For X4-4: Three 800 GB Sun FlashAccelerator F80 PCIe
cards
For X3-4: Six 400 GB Sun FlashAccelerator F40 PCIe cards
One tool-less rack-mount slide-rail kit
One cable management arm
Two front, two rear, and one internal
One front and one rear high-density DB-15 video port
The rear VGA port supports VESA Device Data Channel for
monitor identification.
For X6-4, X5-4, and X4-4: Eleven PCI Express 3.0 slots
that accommodate low-profile PCIe cards.
• All slots support x8 PCIe connections
• Slots 1 through 7, 9, and 10: x8-only connectors
• Slots 8 and 11: x8 or x16 connectors
For X3-4 and X2-4: Ten PCI Express 2.0 slots that
accommodate low-profile PCIe cards.
• Slots 0 and 9: x4 electrical interface
• Slots 1, 2, 4, 6, 7, and 8: x8 electrical interface
• Slots 3 and 5: x8 or x16 electrical interface (x16
connector)
