Oracle Exalytics In-Memory Machine Hardware - Oracle Exalytics In-Memory Machine Owner's Manual

Table 2-1

Oracle Exalytics In-Memory Machine Hardware

Component
Core Components
Compute Server
Power Supply
System Processor
System Memory
SAS Host Bus Adapter (HBA)
InfiniBandHost Channel Adapter
(HCA)
Ethernet Network Interface Card
(NIC)
Description
For X6-4 and X5-4: Oracle Server X5-4
For X4-4: Sun Server X4-4
For X3-4 and earlier: One Sun Fire X4470 M2 server
Two power supply units: 1U A239A 2000-watt AC power
supply
For X6-4: Four CPUs: E7-8895v3, 18C, 2.6 GHz, 155W,
44MB Cache, 8 GT/s QPI, Intel Turbo Boost Technology,
Intel HT Technology Processor with Heatsink. X-Option.
RoHS
For X5-4: Four CPUs: E7-8895v3, 18C, 2.6 GHz, 155W,
44MB Cache, 8 GT/s QPI, Intel Turbo Boost Technology,
Intel HT Technology Processor with Heatsink. X-Option.
RoHS
For X4-4: Four CPUs: E7-8895v2, 15C, 2.8 GHz, 155W,
37.5MB Cache, 8 GT/s QPI, Intel Turbo Boost Technology,
Intel HT Technology Processor with Heatsink. X-Option.
RoHS
For X3-4 and earlier: Four CPUs: E7-4870, 10C, 2.4 GHz,
130W, 30MB Cache, 6.4 GT/s QPI, Intel Turbo Boost
Technology, Intel HT Technology Processor with Heatsink.
X-Option. RoHS
For X6-4 and X5-4: Sixty-four dual in-line memory modules:
32 GB, DDR3 LRDIMM-1600 (total system memory: 2 TB
per server, upgradable to 3 TB)
For X4-4: Sixty-four dual in-line memory modules: 32 GB,
DDR3 LRDIMM-1600 (total system memory: 2 TB per
server, upgradable to 3 TB)
For X3-4: Sixty-four dual in-line memory modules: 32 GB,
DDR3 RDIMM-1066 (total system memory: 2 TB per server)
For X2-4: Sixty-four dual in-line memory modules: LV
DIMM, 16 GB, DDR3-1066, 1.35V (total system memory: 1
TB per server, upgradable to 2 TB)
For X6-4, X5-4: One Sun Storage 12 Gb SAS-3 PCIe RAID
host bus adapter
For X4-4 and earlier: One SAS-2 8-port internal (2x4), 6
Gb, RAID PCIe Gen 2 host bus adapter
For X6-4, X5-4, and X4-4: One Sun Dual Port QDR
Infiniband host channel adapter for PCI Express Gen 3;
Infiniband CX3
For X3-4 and earlier: One 2-port QDR InfiniBand host
channel adapter
For X6-4 and X5-4: Two Dual-Port 10 Gigabit-Ethernet
PCIe 2.0 Copper/Fiber SFP+ cards
For X4-4: Available as an option- One Dual-Port 10 Gigabit-
Ethernet PCIe 2.0 Copper/Fiber SFP+ card
For X3-4 and earlier: One Dual-Port 10 Gigabit-Ethernet
PCIe 2.0 Copper/Fiber SFP+ card
Chapter 2
Hardware Configuration
2-2
